Chapter7 Security Configuration
7-7
Objective
Procedure
dscp (dscp
field|af11|af12|af13|af21|af22|af23|af31|af32|af33|af41|af42|af43|cs1|cs2
|cs3|cs4|cs5|cs6|cs7|default|ef) fragment
filter filter number src-ip { src-ip-address | any} src-mask {src-ip-mask |
any} dst-ip {dst-ip-address | any} dst-mask {dst-ip-mask | any}
dscp(dscp field
|af11|af12|af13|af21|af22|af23|af31|af32|af33|af41|af42|af43|cs1|cs2|cs3
|cs4|cs5|cs6|cs7|default|ef) fragment
filter filter number ip (src-ip-address/M |any) (dst-ip-address M |any)
proto-type proto-type field
filter filter number src-ip { src-ip-address | any} src-mask
{src-ip-mask | any} dst-ip {dst-ip-address | any} dst-mask {dst-ip-mask |
any} proto-type proto-type field
filter filter number ip (src-ip-address/M |any) (dst-ip-address M |any)
ttl ttl field
filter filter number src-ip { src-ip-address | any} src-mask
{src-ip-mask | any} dst-ip {dst-ip-address | any} dst-mask {dst-ip-mask |
any} ttl ttl field
4. (Optional) Use the following commands to configure ACL rule
matching TCP;
filter filter number tcp (src-ip-address/M |any) (<0-65535>|<0-
65535>/<0-65535>|any) (dst-ip-address/M |any) (<0-65535>|<0-
65535>/<0-65535>|any)
filter filter number tcp src-ip { src-ip-address | any} src-mask src-ip-
mask (<0-65535>|any) dst-ip { src-ip-mask | any} dst-mask dst-ip-
mask (<0-65535>|any)
filter filter number tcp (src-ip-address/M |any) (<0-65535>|<0-
65535>/<0-65535>|any) (dst-ip-address/M |any) (<0-65535>|<0-
65535>/<0-65535>|any) fragment
(syn|synack|ack|fin|finack|psh|rst|urg|field|)
filter filter number tcp src-ip { src-ip-address | any} src-mask src-ip-
mask (<0-65535>|any) dst-ipdst-ip-addres dst-mask dst-ip-mask (<0-
65535>|any)(syn|synack|ack|fin|finack|psh|rst|urg| field|) fragment
5. (Optional) Use the following commands to configure ACL rule
matching ICMP;
filter filter number icmp (src-ip-address/M |any) (dst-ip-address M
|any)
filter filter number icmp src-ip { src-ip-address | any} src-mask
{ src-ip-mask | any} dst-ip src-ip-mask dst-mask { dst-ip-mask }
filter filter number icmp (src-ip-address/M |any) (dst-ip-address M
