Chapter7 Security Configuration
7-13
Objective
Procedure
Create one layer3
ACL6
1. Use command of configure to enter Global Configuration View;
2. Use command of filter-list acl-number to create one layer3 ACL6
and enter Layer3 ACL6 Configuration View;
3. End.
Configure layer3
ACL6 rule
1. Use command of configure to enter Global Configuration View;
2. Use command of filter-list acl-number to enter Layer3 ACL6
Configuration View;
[ User can choose from step3 to step8 to configure according your
need.]
3. (Optional) Use the following commands to configure ACL rule
matching IPv6;
filter rule-number ip6 { src-ip6-address/M | any} { dst-ip6-address/M |
any }
filter rule-number ip6 { src-ip6-address/M | any} { dst-ip6-address/M |
any } next-header next-header value
filter rule-number ip6 { src-ip6-address/M | any} { dst-ip6-address/M |
any } hop-limit hop-limit value
4. (Optional) Use the following commands to configure ACL rule
matching TCP6;
filter filter number tcp6 (src-ip6-address/M |any) (<0-65535>|<0-
65535>/<0-65535>|any) (dst-ip6-address/M |any) (<0-65535>|<0-
65535>/<0-65535>|any)
filter filter number tcp6 (src-ip6-address/M |any) (<0-65535>|<0-
65535>/<0-65535>|any) (dst-ip6-address/M |any) (<0-65535>|<0-
65535>/<0-65535>|any)
(syn|synack|ack|fin|finack|psh|rst|urg|field) fragment
5. (Optional) Use the following commands to configure ACL rule
matching ICMP6;
filter filter number icmp6 (src-ip6-address/M |any) (dst-ip6-address M
|any)
filter filter number icmp6 (src-ip6-address/M |any) (dst-ip6-address M
|any) (icmp type|any) (icmp code|any)
6. (Optional) Use the following commands to configure ACL rule
matching IGMP6;
filter filter number igmp6 (src-ip6-address/M |any) (dst-ip6-address
M |any)
7. (Optional) Use the following commands to configure ACL rule
matching UDP6;
filter filter number udp6 (src-ip6-address/M |any)
(<0-65535>|<0-65535>/<0-65535>|any) (dst-ip6-address/M |any)
