Chapter7 Security Configuration
7-17
Objective
Procedure
time-range RANGE-NUMBER absolute from hh:mm:ss YY/MM/DD
or
time-range RANGE-NUMBER absolute from hh:mm:ss YY/MM/DD to
hh:mm:ss YY/MM/DD;
4. Use command of time-range RANGE-NUMBER everyday hh:mm:ss to
hh:mm:ss to configure everyday time range of time-range module;
5. Use command of time-range RANGE-NUMBER everyhour mm:ss to
mm:ss to configure every hour range of time-range module;
6. Use command of time-range RANGE-NUMBER everymonth hh:mm:ss
MM to hh:mm:ss MM to configure every month range of time-range module;
7. Use command of time-range RANGE-NUMBER everyweek hh:mm:ss
(mon|tue|wed|thu|fri|sat|sun) to hh:mm:ss (mon|tue|wed|thu|fri|sat|sun) to
configure every week range of time-range module;
8. Use command of time-range RANGE-NUMBER everyweekday
hh:mm:ss to hh:mm:ss to configure weekday range of time-range module;
9. Use command of time-range RANGE-NUMBER everyweekend
hh:mm:ss to hh:mm:ss to configure weekend range of time-range module;
10. Use command of time-range RANGE-NUMBER everyyear hh:mm:ss
MM/DD to hh:mm:ss MM/DD to configure every year range of time-range
module;
11. Use command of quit to exit to Global Configuration View;
12. Use command of filter-list acl-number to enter ACL Configuration
View;
13. Use command of time-range list time-range acl-number to bind time
range module with ACL;
14. End.
Create ACL
rate limitation
template
1. Use command of configure to enter Global Configuration View;
2. Use the following commands to configure Meter template;
meter meter-number cir CIR-number cbs CBS-number ebs EBS-number
meter meter-number cir CIR-number cbs CBS-number ebs EBS-number
(aware|blind)
meter meter-number cir CIR-number cbs CBS-number pbs PBS-number
pir PIR number
meter meter-number cir CIR-number cbs CBS-number pbs PBS-number
pir PIR number (aware|blind)
3. Use command of filter-list acl-number to enter ACL Configuration View;
4. Use command of filter rule-number meter meter-number to bind ACL
rule with one meter template;
5. Use the following commands to configure how to deal with the coloring
packet according to rate limitation template;
