Chapter1 Basic Configuration
1-20
FTP Server: User is allowed to access FTP server and visit files within, by running
FTP client to log into the server (before the user login, network administrator has to
get IP address of FTP server configured in advance).
The FTP client provided by the switch as an application module belongs to an
accessorial function for user that does not take responsibility of functional
configuration. The switch as the FTP client at the time, connects with remote server,
and corresponding operations (such as category create and delete and so on) can be
achieved by typing FTP client commands.
FTP Client Service: After the connection with the switch (FTP Client) is established via
PC terminal emulation program or telnet, the user is allowed to establish connection
between switch and remote FTP server by inputting command „ftp x.x.x.x‟ (x.x.x.x
indicates IP address of remote FTP server) so that to visit files in remote FTP server.
The QSW-2800 Switch supports FTP functionalities under two types of network
address, IPv4 and IPv6.
1.4.1.2 Enable/Disable FTP Server
Purpose
This section introduces how to enable or disable FTP server.
Process
According to the different purposes, execute corresponding step. Please refer to the
following table.
Purpose
Process
Enable server
1. Use command of configure to enter the Global
Configuration View;
2. Use command of ftpd for device FTP server enabling;
3. Done.
Disable server
1. Use command of configure to enter the Global
Configuration View;
2. Use command of no ftpd for device FTP server disabling;
3. Done.
1.4.1.3 FTP Upload File
Purpose
This section introduces how to upload file through FTP.
