Chapter2 Layer 2 Ethernet Configuration
2-39
Objective
Step
Parameter
vlan-id1/vlan-id2 } delete inner delete outer nto1
translation-vlan map-index inner-vlan { vlan-id | vlan-
id1/vlan-id2 } delete inner { replace | add } [nto1] outer
outervlan-id
translation-vlan map-index inner-vlan { vlan-id | vlan-
id1/vlan-id2 } delete inner { replace | add } [nto1] outer
outervlan-id priority priority
translation-vlan map-index inner-vlan { vlan-id |
vlan-id1/vlan-id2 } replace inner innervlan-id [nto1]
translation-vlan map-index inner-vlan { vlan-id |
vlan-id1/vlan-id2 } replace inner innervlan-id [nto1] priority
inner-priority
translation-vlan map-index inner-vlan { vlan-id | vlan-
id1/vlan-id2 } replace inner innervlan-id delete outer [nto1]
translation-vlan map-index inner-vlan { vlan-id | vlan-
id1/vlan-id2 } replace inner innervlan-id [nto1] priority inner-
priority delete outer
translation-vlan map-index inner-vlan { vlan-id |
vlan-id1/vlan-id2 } replace inner innervlan-id [nto1] { replace
| add } outer outervlan-id
translation-vlan map-index inner-vlan { vlan-id | vlan-
id1/vlan-id2 } replace inner innervlan-id [nto1] priority inner-
priority { replace | add } outer outervlan-id
translation-vlan map-index inner-vlan { vlan-id |
vlan-id1/vlan-id2 } { replace | add } outer outervlan-id [nto1]
translation-vlan map-index inner-vlan { vlan-id |
vlan-id1/vlan-id2 } { replace | add } outer outervlan-id [nto1]
priority outer-priority
translation-vlan map-index inner-vlan { vlan-id | vlan-
id1/vlan-id2 } inner-pri priority delete { inner | outer } [nto1]
translation-vlan map-index inner-vlan { vlan-id | vlan-
id1/vlan-id2 } inner-pri priority delete inner delete outer [nto1]
translation-vlan map-index inner-vlan { vlan-id | vlan-
id1/vlan-id2 } inner-pri priority delete inner { replace | add }
outer outervlan-id [nto1]
translation-vlan map-index inner-vlan { vlan-id |
vlan-id1/vlan-id2 } inner-pri priority delete inner { replace |
