Chapter7 Security Configuration
7-24
Switch(configure-filter-ipv4-1001)#filter 1 action permit
Switch(configure-filter-ipv4-1001)#quit
3. Configure ACL to deny Market Dept to access salary query server.
Switch(config)#filter-list 1002
Switch(configure-filter-ipv4-1002)#filter 1 ip 10.164.2.0/24 10.164.9.9/32
Switch(configure-filter-ipv4-1002)#filter 1 action deny
4. Configure ACL to allow Market Dept to access salary query server at
desigenated time interval.
Switch(configure-filter-ipv4-1002)#filter 1 time-range 1
Switch(configure-filter-ipv4-1002)#quit
5. Configure ACL to deny Research & Development Dept to access salary query
server.
Switch(configure)# filter-list 1003
Switch(configure-filter-ipv4-1003)#filter 1 ip 10.164.3.0/24 10.164.9.9/32
Switch(configure-filter-ipv4-1003)#filter 1 action deny
6. Configure ACL to allow Research & Development Dept to access salary query
server at desigenated time interval.
Switch(configure-filter-ipv4-1003)#filter 1 time-range 1
Switch(configure-filter-ipv4-1003)#quit
7. Apply ACL to interface.
Switch(config)#interface fastethernet 1/0/1
Switch(config-ge1/0/1)#filter-list in 1001
Switch(config-ge1/0/1)#quit
Switch(config)#interface fastethernet 1/0/2
Switch(config-ge1/0/2)#filter-list in 1002
Switch(config-ge1/0/2)#quit
Switch(config)#interface fastethernet 1/0/3
Switch(config-ge1/0/3)#filter-list in 1003
7.2.8.3 Configure Mixed ACL
Network Requirements
Switch is used as gateway, connecting with user PC. Require to configure ACL to
send message with source MAC of 00:01:02:00:00:00/24 and source IP of 1:2:3:1/24
network segment to CPU.
Network Diagram
