Chapter2 Layer 2 Ethernet Configuration
2-41
Objective
Step
Parameter
outer-vlan { vlan-id | vlan-id1/vlan-id2 } delete inner { replace
| add } outer outervlan-id [nto1]
translation-vlan map-index inner-vlan innervlan-id
outer-vlan { vlan-id | vlan-id1/vlan-id2 } delete inner { replace
| add } outer outervlan-id [nto1] priority outer-priority
translation-vlan map-index inner-vlan innervlan-id outer-
vlan { vlan-id | vlan-id1/vlan-id2 } replace inner innervlan-id2
[nto1]
translation-vlan map-index inner-vlan innervlan-id outer-
vlan { vlan-id | vlan-id1/vlan-id2 } replace inner innervlan-id2
[nto1] priority inner-priority
translation-vlan map-index inner-vlan innervlan-id outer-
vlan { vlan-id | vlan-id1/vlan-id2 } replace inner innervlan-id2
delete outer[nto1]
translation-vlan map-index inner-vlan innervlan-id outer-
vlan { vlan-id | vlan-id1/vlan-id2 } replace inner innervlan-id2
[nto1] priority inner-priority delete outer
translation-vlan map-index inner-vlan innervlan-id outer-
vlan { vlan-id | vlan-id1/vlan-id2 } replace inner innervlan-id2
{ replace | add } outer outervlan-id [nto1]
translation-vlan map-index inner-vlan innervlan-id outer-
vlan { vlan-id | vlan-id1/vlan-id2 } replace inner innervlan-id2
{ replace | add } outer outervlan-id [nto1] priority outer-
priority
translation-vlan map-index inner-vlan innervlan-id outer-
vlan { vlan-id | vlan-id1/vlan-id2 } replace inner innervlan-id2
[nto1] priority inner-priority { replace | add } outer outervlan-
id
translation-vlan map-index inner-vlan innervlan-id outer-
vlan { vlan-id | vlan-id1/vlan-id2 } replace inner innervlan-id2
[nto1] priority inner-priority { replace | add } outer outervlan-
id priority outer-priority
translation-vlan map-index inner-vlan innervlan-id outer-
vlan { vlan-id | vlan-id1/vlan-id2 } { replace | add } outer
outervlan-id [nto1]
translation-vlan map-index inner-vlan innervlan-id outer-
vlan { vlan-id | vlan-id1/vlan-id2 } { replace | add } outer
outervlan-id [nto1] priority outer-priority
translation-vlan map-index outer-vlan { vlan-id |
vlan-id1/vlan-id2 } delete { inner | outer } [nto1]
