Chapter2 Layer 2 Ethernet Configuration
2-42
Objective
Step
Parameter
translation-vlan map-index outer-vlan { vlan-id |
vlan-id1/vlan-id2 } delete inner delete outer [nto1]
translation-vlan map-index outer-vlan { vlan-id | vlan-
id1/vlan-id2 } delete inner { replace | add } outer outervlan-id
[nto1]
translation-vlan map-index outer-vlan { vlan-id | vlan-
id1/vlan-id2 } delete inner { replace | add } outer outervlan-id
[nto1] priority outer-priority
translation-vlan map-index outer-vlan { vlan-id | vlan-
id1/vlan-id2 } { replace | add } inner innervlan-id delete outer
[nto1]
translation-vlan map-index outer-vlan { vlan-id | vlan-
id1/vlan-id2 } { replace | add } inner innervlan-id [nto1]
priority inner-priority delete outer
translation-vlan map-index outer-vlan { vlan-id | vlan-
id1/vlan-id2 } { replace | add } { inner | outer } VLAN-ID
[nto1]
translation-vlan map-index outer-vlan { vlan-id | vlan-
id1/vlan-id2 } { replace | add } { inner | outer } VLAN-ID
[nto1] priority priority
translation-vlan map-index outer-vlan { vlan-id | vlan-
id1/vlan-id2 } { replace | add } inner innervlan-id [nto1]{
replace | add } outer outervlan-id
translation-vlan map-index outer-vlan { vlan-id | vlan-
id1/vlan-id2 } { replace | add } inner innervlan-id [nto1]
priority inner-priority { replace | add } outer outervlan-id
translation-vlan map-index outer-vlan { vlan-id |
vlan-id1/vlan-id2 } { replace | add } inner innervlan-id
{ replace | add } outer outervlan-id [nto1] priority
outer-priority
translation-vlan map-index outer-vlan { vlan-id | vlan-
id1/vlan-id2 } { replace | add } inner innervlan-id [nto1]
priority inner-priority { replace | add } outer outervlan-id
priority outer-priority
translation-vlan map-index outer-pri priority delete { inner |
outer } [nto1]
translation-vlan map-index outer-pri priority delete inner
delete outer [nto1]
translation-vlan map-index outer-pri priority delete inner
{ replace | add } outer outervlan-id [nto1]
