GRAPHITE 18
19
• Install air filter. Ensure the grooves on the air filter rim match
protrusions on the air filter lid (4).
• When installing the air filter lid (4) make sure to properly place ignition
plug wire and access sleeves for carburettor adjustment screws.
Do not wash the air lter in petrol or any other ammable solvent
to avoid re hazard or appearance of dangerous vapours.
CYLINDER FINNING
Dust deposition on the cylinder finning may cause motor
overheating. Check regularly and clean the cylinder finning when
carrying out maintenance of the air filter.
GUIDE BAR AND CHAIN
Check condition of the guide bar and chain every 5 hours of the saw
operation.
• Set the ignition switch (14) to off position.
• Loosen and unscrew the guide bar fixing nuts (7).
• Remove the casing (10) and disassemble guide bar (20) and chain
(21).
• Clean oil holes and groove (e) in the guide bar (20) (g. U).
• Lubricate tip chain wheel of the guide bar (22) through the hole (f)
located on the guide bar tip (g. W).
• Check condition of the chain (21).
CHAIN SHARPENING
Pay attention to cutting tools. Cutting tools should be sharp and
clean, it allows efficient and safe operation. Operating the saw with
blunt chain causes quick wear of the chain, guide bar and driving
chain wheel, and breaking the chain in the worst case. That is why it
is important to sharpen the chain on time.
Chain sharpening is a complex operation. Sharpening the chain by
yourself requires use of special tools and skills. It is recommended to
entrust sharpening the chain to qualified persons.
FUEL FILTER
• Unscrew the fuel filler plug (15).
• Use wire hook to remove the fuel filter (g) through the fuel filler
hole (g. X).
• Disassemble the fuel filter and wash it in petrol or replace with
a new one.
• Install the fuel filter in the tank.
• Tighten the fuel filler plug (15).
When the lter has been dismantled use the wire hook to hold up
the end of the suction line.
Be careful during fuel lter installation to prevent contamination
from getting into the suction line.
OIL FILTER
• Unscrew oil filler plug (18).
• Use wire hook to remove the oil filter (h) through the oil filler hole
(g. Y).
• Wash the oil filter in petrol or replace with a new one.
• Remove dirt from the tank.
• Install the oil filter in the tank.
• Tighten oil filler plug (18).
When putting the oil lter into the tank make sure it reaches front
right corner.
IGNITION PLUG
To maintain reliable operation of the device, check condition of the
ignition plug on a regular basis.
• Remove air filter lid (4).
• Remove air filter (d).
• Remove wire (i) from the ignition plug.
• Put on plug key (included) and unscrew the ignition plug (g. Z).
• Clean and adjust spacing between contacts (0.65 mm) (replace
ignition plug when necessary).
OTHER INSTRUCTIONS
Ensure there are no fuel leaks, loosened joints or damages of main
parts, especially main handle joints and guide bar fixing. When you
find any damage, make sure it is repaired before next use of the
chain saw.
All faults should be repaired by service workshop authorized by the
manufacturer.
TECHNICAL PARAMETERS
RATED PARAMETERS
Petrol Chain Saw
Rated parameter Value
Engine displacement 45 cm
3
Guide bar working length 360 mm
Engine power 1,8 kW (2,45 KM)
Engine speed with cutting system
(maximum)
10000 min
-1
Idle rotational speed 2800±200 min
-1
Average fuel consumption 0,85 l/h
Fuel Petrol / oil (for 2-stroke
engines) 25:1
Fuel tank capacity 580 ml
Chain oil SAE10W-30
Chain oil tank capacity 250 ml
Carburettor WT819 Walbro
Ignition system Spark
Ignition plug BM6A/Torch
Oil feed system Automated pump with
controller
Chain wheel (teeth x pitch) 7T x 8,255 mm
Type of guide bar 112364 91
Type of chain 21LPX072X Oregon
Chain pitch 0,325” (8,255mm)
Chain thickness 0,058” (1,47 mm)
Dimensions (LxWxH) (w/o guide
bar)
390 x 230 x 280 mm
Weight (w/o guide bar and chain) 5,5 kg
Chain guiding in guide bar Bearing mounted toothed
wheel
Year of production 2016
NOISE LEVEL AND VIBRATION PARAMETERS
Sound pressure: Lp
A
= 96 dB(A) K=3dB(A)
Sound power: Lw
A
= 114 dB(A) K=3dB(A)
Vibration acceleration a
h
:
- front handle: a
h
= 8,5 m/s
2
K=1,5 m/s
2
ENVIRONMENT PROTECTION
Do not dispose of electrically powered products with household wastes,
they should be utilized in proper plants. Obtain information on wastes
utilization from your seller or local authorities. Used up electric and
electronic equipment contains substances active in natural environment.
Unrecycled equipment constitutes a potential risk for environment and
human health.
* Right to introduce changes is reserved.
