ENGINE TOP END 5-3
Exploded View
Torque
No. Fastener
N·m
kgf·m ft·lb
Remarks
1 Auto decompressor bolt 12 1.2 104 in·lb
2
Cylinder head cover bolts
9.8 1.0 87 in·lb
3 Cylinder head bolts M6 12 1.2 104 in·lb S
4
Camshaft cap bolts
12 1.2 104 in·lb
S
5 Carburetor holder clamp screws 2.0 0.2 17 in·lb
6 Plug 20 2.0 14 L
7 Lower camshaft chain guide bolt 9.8 1.0 87 in·lb
8
Cylinder head bolts M10
50 5.0 36
S
9 Rear camshaft chain guide bolt 15 1.5 11
10 Exhaust pipe stud – – –
L (Planted side)
11. Closed coil end faces down.
EO: Apply engine oil.
L: Apply non-permanent locking agent.
M: Apply molybdenum disulfide grease.
MO: Apply molybdenum disulfide oil.
R: Replacement Parts
S: Follow the specific tightening sequence.
SS: Apply silicon sealant.
