1-8 GENERAL INFORMATION
General Specifications
Items KX250–N1
Dimensions:
Overall length 2 170 mm (85.43 in.)
Overall width 840 mm (33.1 in.)
Overall height 1 270 mm (50 in.)
Wheelbase 1 475 mm (8.07 in.)
Road clearance 340 mm (13.4 in.)
Seat height 960 mm (37.8 in.)
Dry m ass 92.5 kg (204 lb)
Curb mass: Front 49.9 kg (110 lb)
Rear 52.6 kg (116 lb)
Fuel tank capacity 7.5 L (2.0 US gal)
Performance
Minimum turning radius —
Engine:
Type 4-stroke, single cylinder, DOHC 4 valve
Cooling system Liquid-cooled
Bore and stroke 77.0 × 53.6 mm (3.03 × 2.11 in.)
Displacement 249 mL (15.2 cu in.)
Compression ratio 12.6 : 1
Maximum horsepower 31.6 kW (43.0 P S) @11 000 r/min (rpm)
Maximum torque 28.7 N·m (2.93 kgf·m, 6.45 in·lb) @ 8 500 r/min (rpm)
Carburetion system Carburetor, KEIHIN FCR37
Starting system Primary kick
Ignition system Digital AC-CDI
Timing advance
Ignition timing
BTDC 8° @ 2 000 r/min (rpm)
Spark plug NGK CR8EB or NGK CR9EB
Valve timing
Inlet Open BTDC 49°
Close ABDC 63°
Duration 292°
Exhaust O pen BBDC 69°
Close ATDC 49°
Duration 298°
Lubrication system Forced lubrication (semi-dry sump)
Engine oil:
Type
API SH or SJ with JASO MA
Viscosity
SAE 10W-40
Capacity 1.5 L (1.6 USqt)
Drive Train:
Primary reduction system:
Type Gear
Reduction ratio 3.350 (67/20)
Clutch type Wet, multi disc
