PERIODIC MAINTENANCE 2-25

Periodic Maintenance Procedures

•

Using the pry point [A], remove the water pump cover [B].

•

Remove the oil filter [A].

•

Replace the oil filter with a new one.

•

Apply grease to the grom met.

•

Be sure to install the filter with the grommet [A] facing

inside as shown.

CAUTION

Inside–out installation stop oil flow, causing engine

seizure.

•

Install the spring [A] and dowel pins [B].

Replace the pump cover gasket [C] with a new one.

•

Apply grease to the pump cover gasket.

•

Install the water pump cover and water pipe (see Cooling

System chapter).

•

Tighten:

○

Apply a non-permanent locking agent to two cover bolts

(see Cooling System chapter).

○

Tighten two cover bolt with the washer (see Cooling Sys-

tem chapter).

Torque - Water Pump Cover Bolts : 9.8 N·m (1.0 kgf·m, 87

in·lb)

Water Pump Cover Bolts (with washer) : 7.0 N·m

(0.7 kgf·m, 61 in·lb)

Coolant Drain Plug : 7 .0 N·m (0.7 kgf·m, 61 in·lb)

Water Pipe Bolt : 9.8 N·m (1.0 kgf·m , 87 in·lb)

•

Pour in the specified type and amount of oil (see Engine

Oil Change) and coolant (see Cooling System chapter).
