BRAKES 12-3
Exploded View
Torque
No. Fastener
N·m kgf·m ft·lb
Remarks
1 Front master cylinder clamp bolts 8.8 0.9 78 in·lb
2 Brake hose banjo bolts 25 2.5 18
3 Brake pad bolt 18 1.8 13
4
Caliper bleed valve
7.8 0.8 69 in·lb
5 Caliper mounting bolts 25 2.5 18
6 Brake disc mounting bolts 9.8 1.0 87 in·lb L
7 Brake lever pivot bolt locknut 5.9 0.6 52 in·lb
8 Brake reservoir cap screws 1.5 0.15 13 in·lb
9 Brake lever pivot bolt 5.9 0.6 52 in·lb
10. Front Brake Reservoir
11. Brake Lever
12. Brake Lever Adjuster
13. Locknut
14. Brake Hose
15. Clamps
16. Front Caliper
17. Brake Pad
18. Piston
19. Front D isc
BF: Apply brake fluid.
L: Apply a non-permanent locking agent.
Si: Apply Silicone grease.
R: Replacement Parts.
