CRANKSHAFT/TRANSMISSION 9-3

Exploded View

Torque

No. Fastener

N·m

kgf·m ft·lb

Remarks

1 Crankcase bolts 9.8 1.0 87 in·lb S

Gear set lever nut

8.8 0.9 78 in·lb

3 Neutral switch 12 1.2 104 in·lb

Engine oil drain plug (for crank room oil sump)

7.0 0.7 61 in·lb

5 Engine oil drain plug (for transmission room oil sump) 15 1.5 11

Shift drum cam bolt

24 2.4 17 L

7 Piston oil nozzle 2.5 0.25 22 in·lb L

8 Reed valve screws 7.0 0.7 61 in·lb

9 Drive shaft bearing retaining screw 6.4 0.65 56 in·lb L

Output shaft bearing retaining screw

6.4 0.65 56 in·lb L

11 Shift dram bearing retaining bolts 9.8 1.0 87 in·lb L

Breather fitting

15 1.5 11 L

13. Reed Valve

EO: Apply engine oil.

HG: Apply high temperature grease.

L: Apply a non-permanent locking agent.

LG: Apply liquid gasket.

R: Replacement parts

S: Tighten the fasteners following the specified sequence.
