STEERING 14-3
Exploded View
Torque
No. Fastener
N·m kgf·m ft·lb
Remarks
1 Handlebar clamp bolts 25 2.5 18.0 S
2 Steering stem head nut 78 8.0 58
3 Steering stem locknut 4.9 0.5 43 in·lb T
4 Upper front fork clamp bolts 20 2.0 14.5 AL
5 Lower front fork clamp bolts 20 2.0 14.5 AL
6. Handlebar Clamp
7. Handlebar
8. Handlebar Holder
9. Steering Stem Head Bracket
10. Upper Tapered Roller Bearing
11. Head Pipe
12. Lower Tapered Roller Bearing
13. Steering Stem
AL: Tighten the two clamp bolts alternately two times to ensure even tightening torque.
AD: Apply adhesive c ement
G: Apply grease
O: Apply 2 Stroke Oil
T: Tighten all snugly, then loosen, Retighten to 4.9 N·m (0.5 kgf·m, 43 in·lb).
S: Follow the specific tightening sequence.
