PERIODIC MAINTENANCE 2-9

Specifications

Item Standard Service Limit

Wheels/Tires:

Rim Runout:

Axial Under 1.0 mm (0.039 in.) 2 mm (0.08 in.)

Radial Under 1.0 mm (0.039 in.) 2 mm (0.08 in.)

Front and rear tires air pressure 100 kPa (1.0 kgf/cm², 14 psi)

Standard tire:

Front: Size 80/100-21 51M ---

Make BRIDESTONE

Type M601, Tube (EU) M201, Tube

Rear: Size 100/90-19 57M ---

Make BRIDESTONE

Type M602, Tube (EU) M202, Tube

Final Drive:

Drive chain slack 52 ∼ 62 mm (2.05 ∼ 2.44 in.) ---

Drive chain 20 link length 317.5 ∼ 318.2 mm 323 mm

(12.50 ∼ 12.53 in.) (12.72 in.)

Engine sprocket diameter 55.48 ∼ 55.68 mm 54.8 mm

(2.184 ∼ 2.192 in.)/13T (2.157 in.)

Rear sprocket diameter 232.62 ∼ 233.12 mm 232.1 mm

(9.158 ∼ 9.178 in.)/48T (9.138 in.)

Rear sprocket warp Under 0.4 m m (0.016 in.) 0.5 mm (0.020 in.)

Brakes:

Brake lever free play (to suit rider) ---

Brake fluid:

Type: Front DOT3 or DOT4 ---

Rear DOT4 ---

Brake pad lining thickness: Front 3.8 mm (0.150 in.) 1 mm (0.04 in.)

Rear 6.4 mm (0.252 in.) 1 mm (0.04 in.)

Suspension:

Fork Oil:

Oil viscosity KAYABA 01 or SAE 5W

Oil capacity (per unit) 564 ± 4 mL (19.07 ± 0.14 US oz.) ---

(Adjustable range)

Oil level (fully compressed, spring

removed)

95 mm (3.7 in.) 70 ∼ 120 mm

Electrical System: (2.8 ∼ 4.7 in.)

Spark plug gap 0.7 ∼ 0.8 mm (0.028 ∼ 0.031 in.) ---

TIR: Total Indicator Readings
