10-4 WHEELS/TIRES
Specifications
Item Standard Service Limit
Wheels (Rims):
Rim runout: Axial 1.0 mm (0.039 in.) or less 2 m m (0.08 in.)
Radial 1.0 mm (0.039 in.) or less 2 m m (0.08 in.)
Axle runout/ 100 mm 0.1 mm (0.004 in.) 0.2 mm (0.008 in.)
Tires Air Pressure:
Front and Rear 100 kPa ( 1.0 kgf/cm², 14 psi) ---
Tires :
Standard tire:
Front: Size 80/100-21 51M ---
Make BRIDESTONE
Type M601, Tube (EU) M201, Tube
Rear: Size 100/90-19 57M ---
Make BRIDESTONE
Type M602, Tube (EU) M202, Tube
