7-6 ENGINE LUBRICATION SYSTEM
Specifications
Item Standard
Engine Oil:
Grade Castrol “R4 Superbike” 5W-40
API SH or SJ w ith J ASO MA
Viscosity SAE 10W-30, 10W-40, or 10W-50
Capacity
Oil change – when filter is not removed 1.3L(1.4USqt)
Oil change – when filter is removed 1.35 L (1.43 US qt)
when engine is completely dry 1.5L(1.6USqt)
Oil level (after warm–up or driving) Upper level
Oil Pressure Measurement:
(oil temperature 90°C, engine speed 4 000 rpm) 19.6 kPa (0.2 kgf/cm², 2.8 psi)
