PERIODIC MAINTENANCE 2-7
Torque and Locking Agent
Torque
Fastener
N·m kgf·m ft·lb
Remarks
Push Rod Nut 28 2.85 20.6
Swingarm Pivot Shaft Nut
98 10 72
Rear Shock Absorber Mounting Nuts: (Upper) 39 4.0 29
(Lower) 34 3.5 25
Air Bleed Bolt 6.4 0.65 56 in·lb
Tie-Rod Mounting Nut (Front, Rear) 83 8.5 61
Rocker Arm Pivot Nut 83 8.5 61
Steering:
Steering Stem Head Nut 79 8.0 58
Steering Stem Locknut 4.9 0.5 43 in·lb
Handlebar Clamp Bolts 25 2.5 18 S
Front Fork Clamp Bolts (Upper, Lower)
20 2.0 14.5 AL
Frame:
Rear Frame Mounting Botls 34 3.5 25
Electrical System:
Neutral Switch 12 1.2 104 in·lb
Neutral Switch Lead Terminal Screw 1.3 0.13 12 in·lb
Flywheel Nut 49 5.0 36
Timing Inspection Cap
4.0 0.4 43 in·lb
Stator Bolts
7.0 0.7 61 in·lb
Crankshaft Sensor Bolts 7.0 0.7 61 in·lb
Spark Plug 13 1.3 115 in·lb
C.D.I. Unit Bolts 9.8 1.0 87 in·lb
Magneto Cover Bolts L:30 9.8 1.0 87 in·lb
L:35 9.8 1.0 87 in·lb L
Ignition Coil Bolts 7.0 0.7 61 in·lb
Basic Torque for General Fasteners
Threads dia. Torque
(mm) N·m kgf·m ft·lb
5 3.4 ∼ 4.9 0.35 ∼ 0.50 30 ∼ 43 in·lb
6 5.9 ∼ 7.8 0.60 ∼ 0.80 52 ∼ 69 in·lb
8 14 ∼ 19 1.4 ∼ 1.9 10.0 ∼ 13.5
10 25 ∼ 34 2.6 ∼ 3.5 19.0 ∼ 25
12 44 ∼ 61 4.5 ∼ 6.2 33 ∼ 45
14 73 ∼ 98 7.4 ∼ 10.0 54 ∼ 72
16 115 ∼ 155 11.5 ∼ 16.0 83 ∼ 115
18 165 ∼ 225 17.0 ∼ 23.0 125 ∼ 165
20 225 ∼ 325 23 ∼ 33 165 ∼ 240
