BRAKES 12-11
Brake Fluid
•
Check the fluid level.
•
After bleeding is done, check the brake for good braking
power, no brake drag, and no fluid leakage.
WARNING
Do not attempt to drive the motorcycle until a full
brake lever or pedal is obtained by pumping the
brake lever or pedal until the pads are against the
disc. The brake will not function on the first appli-
cation of the lever or pedal if this in not done.
