13-6 SUSPENSION
Specifications
Item Standard Service Limit
Front Fork:
Air pressure Atmospheric pressure -––
Rebound damping adjustment (Adjustable Range)
11 clicks counterclockwise 16 clicks
(from the seated position adjuster
turned fully clockwise)
12 clicks counterclockwise (EU)
Compression damping adjustment (Adjustable Range)
8 clicks counterclockwise 16 clicks
(from the seated position adjuster
turned fully clockwise)
11 clicks counterclockwise (EU)
Oil viscosity KAYABA 01 or SAE 5W
CORRESPOND
–––
Oil capacity 564 ± 4 mL (19.07 ± 0.14 US oz.) –––
Oil level
(fully compressed, spring removed) (Adjustable Range)
95 mm (3.7 in.) 70 ∼ 120 mm
(from top of outer tube) (2.8 ∼ 4.7 in.)
Fork spring free length 460 mm (18.11 in.) 450 mm (17.72 in.)
Rear Suspension (Uni-Trak):
Rear Shock Absorber:
Rebound damping adjustment (Adjustable Range)
(from the seated position adjuster
turned fully clockwise)
12 clicks counterclockwise 16 clicks
Spring preload adjustment (Adjustable Range)
(Adjusting nut position from the center
of the mounting hole upper)
113 mm (4.41 in.) 109 ∼ 129.5 mm
(4.29 ∼ 5.02 in.)
Rear shock spring free length 260 mm (10.24 in.) 255 mm (10.04 in.)
Gas Reservoir:
Compression damping adjustment (Adjustable Range)
(from the seated position adjuster
turned fully clockwise)
11 clicks counterclockwise 16 clicks
Gas pressure 980 kPa (10 kgf/cm², 142 psi) –––
Tie-Rod, Rocker Arm:
Sleeve outside diameter:
Tie-rod 19.987 ∼ 20.000 mm 19.85 mm
(0.7869 ∼ 0.7874 in.) (0.781 in.)
Rocker Arm Large 19.987 ∼ 20.000 mm 19.85 mm
(0.7869 ∼ 0.7874 in.) (0.781 in.)
Small 15.995 ∼ 16.000 mm 15.85 mm
(0.6297 ∼ 0.6299 in.) (0.624 in.)
Rocker Arm Mounting Bolt Runout under 0.1 mm (0.004 in.) 0.2 mm (0.008 in.)
EU: European Model
