REAR WHEEL AND BRAKE DISC
4-26
CHAS
Lithium-base grease
Check that the brake caliper support has
stayed in the correct position on the rear arm.
CAUTION:
5. Install:
•
Rear wheel assembly (in the rear arm)
•
Bearing
•
Edge of the hub dust cover
Check that the brake disc is driving through
the brake pads.
CAUTION:
Make sure the collars and chain pullers are
positioned correctly.
CAUTION:
6. Install:
•
Drive chain (on the driven sprocket)
•
Rear wheel axle (left side)
7. Adjust:
•
Drive chain slack
Drive chain slack:
30 ~ 40 mm
Refer to “DRIVE CHAIN SLACK INSPEC-
TION AND ADJUSTMENT” section in
Chapter 3.
8. Tighten:
•
Wheel axle nut
Wheel axle nut:
115 Nm (11.5 mkg)
4. Lubricate:
•
Wheel axle
•
Bearings
•
Edge of hub dust cover
