SPEC
MAINTENANCE SPECIFICATIONS
2-10
Tightening
Part
torque
Part to be tightened
name
Thread size Remarks
Nm mkg
Cylinder head Washer
based bol M8 x 1.25 29 2.9
Cylinder head Stud bolt M10 x 1.25 20 2.0
Cylinder head Hexagon socket
head screw M6 x 1.0 10 1.0
Cylinder head Stud bolt M6 x 1.0 7 0.7
Cylinder head:
Cap (oil check) Union bolt M6 x 1.0 7 0.7
Spark plug – M12 x 1.25 18 1.8
Cylinder head cover Hexagon socket
head screw M6 x 1.0 10 1.0
Tappet cover (intake) Hexagon socket
head screw M6 x 1.0 10 1.0
Tappet cover (exhaust) – M32 x 1.5 12 1.2
Cylinder Crown nut M8 x 1.25 22 2.2
Cylinder Nut M10 x 1.25 42 4.2
Cylinder Hexagon socket
head screw M6 x 1.0 10 1.0
Weight drive gear Hexagon nut M16 x 1.0 60 6.0
Rotor (A.C. magneto) Hexagon nut M14 x 1.5 120 12.0
Lock nut (valve adjusting screw) Hexagon nut M6 x 1.0 14 1.4
Cam chain sprocket Washer based
bolt M7 x 1.0 20 2.0
Cam chain stopper guide Hexagon socket
head screw M6 x 1.0 10 1.0
Cam chain stopper guide Washer based
screw M16 x 1.0 20 2.0
Rocker shaft Hexagon socket
head screw M6 x 1.0 10 1.0
Oil pump Hexagon socket
head screw M6 x 1.0 10 1.0
Oil delivery/retrieval pipe Pan screw M6 x 1.0 7 0.7
Oil draining pipe Washer based
screw M14 x 1.5 30 3.0
Oil filter cover Hexagon socket
head screw M6 x 1.0 10 1.0
Bleed screw (oil filter cover) Hexagon screw M5 x 0.8 5 0.5
Push lever (clutch) Pan screw M8 x 1.0 12 1.2
Push rod (clutch) Hexagon nut M6 x 1.0 8 0.8
Sprocket Hexagon nut M18 x 1.0 115 11.5
Lock washer (oil seal) Hexagon screw M6 x 1.0 10 1.0
Stop lever Bolt M6 x 1.0 10 1.0
Shift cam Hexagon screw M6 x 1.0 10 1.0
Stator Pan head (+)
screw M5 x 0.8 5 0.5
Tightening torques
