SPEC
MAINTENANCE SPECIFICATIONS
2-11
Tightening
Part
torque
Part to be tightened
name
Thread size Remarks
Nm mkg
Stator (pick-up coil) Hexagon socket
head screw M6 x 1.0 7 0.7
Engine oil pipe 1 Hexagon socket
head screw M6 x 1.0 10 1.0
Engine oil pipe 2 Union screw M12 x 1.25 35 3.5
Oil delivery pipe Union bolt M8 x 1.25 18 1.8
Carburetor joints Hexagon socket
head screw M6 x 1.0 10 1.0
Air filter case (frame) Hexagon screw M6 x 1.0 10 1.0
Air filter case (frame) Washer based
screw M6 x 1.0 10 1.0
Exhaust pipe Washer based
nut M6 x 1.0 10 1.0
Exhaust pipe protector Pan head (+)
screw M6 x 1.0 7 0.7
Muffler Hexagon socket
head screw M8 x 1.25 23 2.3
Muffler (band) Nut, nylon M8 x 1.25 23 2.3
Muffler Washer based
screw M8 x 1.25 23 2.3
Crankcase Hexagon socket
head screw M6 x 1.0 10 1.0
Crankcase Stud bolt M10 x 1.25 20 2.0
Crankcase cover (right) Hexagon socket
head screw M6 x 1.0 10 1.0
Crankcase cover (left) Hexagon socket
head screw M6 x 1.0 10 1.0
Sprocket cover Hexagon socket
head screw M6 x 1.0 10 1.0
Stop washer (bearing) Flat headscrew M6 x 1.0 7 0.7
Pressure plate Washer based
screw M6 x 1.0 8 0.8
Clutch housing Hexagon nut M20 x 1.0 90 9.0
Primary drive gear Hexagon nut M20 x 1.0 120 12.0
