Yamaha TT600RE (2004) [185/382] Rear shock absorber
![Yamaha TT600RE (2004) [185/382] Rear shock absorber](/views2/1121411/page185/bgb9.png)
REAR SHOCK ABSORBER
4-70
CHAS
Order Job name/Part name Q.ty Remarks
6 Lower bolt 1
7 Upper bolt 1
Reverse the removal procedure for instal-
lation.
