Yamaha TT600RE (2004) [37/382] Maintenance specifications

SPEC

MAINTENANCE SPECIFICATIONS

2-16

Tightening

Part to be tightened

Thread torque

Remarks

size

Starting motor cord/Starting motor M6 x 1.0 11 1.1

Wire minus lead (-)/Starting motor M6 x 1.0 10 1.0

Front flasher lights/Stay, headlight M6 x 1.0 1.5 0.15

Clutch wire/Engine M6 x 1.0 7 0.7

Assist grip (Standing handle)/Rear frame M8 x 1.25 23 2.3

Speedometer M5 x 0.8 4 0.4

Air filter case 1/Air filter case 2 (L = 13 mm) M3.9 0.5 0.05

Air filter case 1/Air filter case 2 (L = 19 mm) M3.9 1 0.1

Hose clamp/Joint, carburator M4 x 0.7 0.6 0.06

Hose clamp/Air cleaner/Carburator M5 x 0.8 0.8 0.08

Battery (+)/(-) M6 x 1.0 2.5 0.25

NOTE:

1. First tighten the ring nut approximately 38 Nm (3.8 mkg) by using the torque wrench, then loosen the

ring nut one turn.

2. Final tighten the ring nut at the torque of 4 Nm (0.4 mkg).
