DEFECTIVE BRAKES/
OIL LEAKS OR MALFUNCTIONING OF FRONT FORK
8-6
TRBL
SHTG
?
PROBABLE CAUSES
•
Brake pads worn
•
Brake disc worn
•
Water in the brake fluid
•
Brake fluid leak
•
Brake fluid tank defective
•
Bleed cap not sealed to calipers
•
Union bolt loose
•
Brake hose cracked
•
Brake disc dirty or greasy
•
Brake pads dirty or greasy
•
Incorrect brake fluid level
POOR BRAKING
DEFECTIVE BRAKES
PROBABLE CAUSES
•
Inner tube deformed, damaged or rusty
•
Outer tube damaged or cracked
•
Oil seal lip damaged
•
Oil seal assembled incorrectly
•
Oil level incorrect (excessive)
•
Shock-absorber rod stop bolt loose
•
O-ring on cap bolt broken
OIL LEAKS
PROBABLE CAUSES
•
Inner tube deformed, damaged or rusty
•
Outer tube deformed or damaged
•
Fork spring damaged
•
Piston worn or damaged
•
Shock-absorber rod deformed or damaged
•
Incorrect oil viscosity
•
Incorrect oil level
MALFUNCTIONING
OIL LEAKS OR MALFUNCTIONING OF FRONT FORK
