CARBURETOR
6-4
CARB
(1) Carburetor
assembly
(2) Cover gasket
(3) Gasket, nozzle
(4) Float
(5) Float pin
(6) Float chamber
gasket
(7) Screw
(8) Float chamber
fastening screw
(9) Spring washer
(10) Collar
(11) Screw
(12) Gasket
(13) Throttle valve
spring
(14) Spring washer
(15) Nut
(16) Gasket
(17) Screw
(18) Stop screw
(19) Nut
(20) Screw
(21) Hose
(22) Diaphragm
(23) Cover
(24) Bracket
(25) O-ring
(26) Spring washer
(27) Spring
(28) Drain valve
(29) Pipe
(30) Pipe
(31) Screw
(32) Screw
(33) Pipe
(34) Clip
(35) Main jet 1
(36) Main nozzle 1
(37) Throttle valve
(38) Pilot jet
(39) Main jet 2
(40) Main nozzle 2
(41) Pilot screw set
(42) Needle valve set
(43) Stop screw set
(44) Throttle screw set
(45) Diaphragm
(46) Needle set 1
(47) Needle set 2
(48) Starter set
(49) Way 3
(50) Hose
(51) Hose
(52) Hose
(53) Clip
(54) Breather pipe
(55) O-ring
(56) Pipe
SPECIFICATIONS
Main jet #150 FIRST
#145 SEC.
Starter jet #74
Needle jet 5C5A-3/5 ( FIRST)
5Y18-3/5 (SEC.)
Main nozzle ø 2,6
Pilot jet #50
Pilot air screw 2,75 ± 0,5 revs approx.,
open
Float height 27~29 mm
Fuel level 6~8 mm
Engine idle speed 1.150~1.450 r/min
Throttle valve seat ø 2,5 mm
