IGNITION SYSTEM
7-12
ELEC
The diagram illustrates the ignition circuit inside the motorcycles electric system.
NOTE:
For the colour code and legend, see page 7-2.
(1) AC generator/Pickup coil
(2) Rectifier/Regulator
(3) Battery
(6) Fuse
(7) Main switch
(9) Engine stop switch
(11) Diode
(12) Clutch switch
(13) Sidestand switch
(14) Neutral switch
(15) Diode
(16) Ignitor unit
(17) Ignition coil
9
17
7
2
3
6
11
1
12
15
16
14
13
