FRONT FORK
4-58
CHAS
WARNING
Do not attempt to straighten a bent inner tube
as this may have dangerous consequences.
4. Inspect:
•
Outer tube (1)
Score marks/Wear/Damage ➔ Replace.
5. Inspect:
•
Cap bolt
•
O-ring
Wear/Damage ➔ Replace.
