CHAS
REAR BRAKE
4-41
4. Inspect:
•
Brake fluid level
Lower than “MIN” mark (1) ➔ Fill.
Refer to “BRAKE FLUID INSPECTION”
section in Chapter 3.
(1) Minimum level mark “MIN”
1
