Part IV
Firewall & IP/MAC Binding
D-Link 100
Step 6. Change the IP/MAC binding to
“Block”
Through the previous steps, we have configured
two IP/MAC rules for allowing passing through
DFL-1500. In this step, we will change the
IP/MAC binding status to “Block” to prohibit
invalid IP address to pass through DFL-1500.
Advanced Settings > IP/MAC Binding > Edit Rules
Step 7. Show the IP/MAC binding rule
After finishing the setting, you can view the result
as the right diagram shown.
Advanced Setting > IP/MAC binding > Show Rules
