Part V
Virtual Private Network
D-Link 168
Step 4. Uncheck the item
Uncheck Active the default response
rule checkbox, and click Next
Step 5. Finish the IP Security policy
creation
Keep the Edit properties check box selected
and click Finish.
Step 6. Edit policy properties
A dialog window will bring up for you to configure
two filter rules for this policy. Click General tab
and click Advanced button to setup IPSec
phase1 parameters.
Step 7. Key Exchange Settings
Click Methods to proceed.
