Part V
Virtual Private Network
D-Link 156
Step 8. Setup IKE Policy
Enter DFL-1500[DES-MD5] as the IKE Policy
name. Select DES/MD5/DH-Group 2 [1024
Bit] in the Encryption/Hash/DH Group field.
Click OK to finish the settings.
Configuration > Profile Settings > Configure > IPSec Geneneral
Settings > Policy editor > IKE Policy
Step 9. Setup IPSec Policy
Enter DFL-1500[DES-MD5] as the IPSec
Policy name. Select DES and MD5 in the
Transform and Authentication field. Click
OK to finish the settings.
Configuration > Profile Settings > Configure > IPSec Geneneral
Settings > Policy editor > IPSec Policy
