DFL-900/1500 User Manual Chapter 1
Quick Start
7
LAN port z 1 port for connecting inbound LAN
z RJ-45 connector
z IEEE 802.3 compliance
z IEEE 802.3u compliance
z Support Half/Full-Duplex operations
z Support backpressure at Half-Duplex operation.
z IEEE 802.3x Flow Control support for
Full-Duplex mode
z 2 ports for connecting inbound LAN
z RJ-45 connector
z IEEE 802.3 compliance
z IEEE 802.3u compliance
z Support Half/Full-Duplex operations
z Support backpressure at Half-Duplex operation.
z IEEE 802.3x Flow Control support for
Full-Duplex mode
DMZ port z 1 port for connecting to server.
z RJ-45 connector
z IEEE 802.3 compliance
z IEEE 802.3u compliance
z Support Half/Full-Duplex operations
z Support backpressure at Half-Duplex operation.
z IEEE 802.3x Flow Control support for
Full-Duplex mode
z 1 port for connecting to server.
z RJ-45 connector
z IEEE 802.3 compliance
z IEEE 802.3u compliance
z Support Half/Full-Duplex operations
z Support backpressure at Half-Duplex operation.
z IEEE 802.3x Flow Control support for
Full-Duplex mode
Console port z DB-9 male connector
z Asynchronous serial DTE with full modem
controls
z No hardware handshaking such as RTS/CTS
z DB-9 male connector
z Asynchronous serial DTE with full modem
controls
LED indication z Power,
Solid Orange – System ready
z Blinking Green – System under power-on self
test
Ethernet 10/100M Per ports:
z Link/ACT LED
Off – No Link
Solid Green – Link
Blinking Green – Activity
z Power,
Solid Orange – System ready
z Blinking Green – System under power-on self
test
Ethernet 10/100M Per ports:
z Link/ACT LED
Off – No Link
Solid Green – Link
Blinking Green – Activity
Power
Power supply AT PS, AC 90~230 V full range @ 45~63 Hz AT PS, AC 90~230 V full range @ 45~63 Hz
Power dissipation 180 W 180 W
Environmental Specifications
Operating Temperature 0 ~ 60°C 0 ~ 60°C
Storage Temperature -25~70°C -25~70°C
Operating Humidity 5% - 95% non-condensing 5% - 95% non-condensing
EMC and Safety Certification
EMC Approval FCC class A
VCCI class A
CE class A
C-Tick class A
FCC class A
VCCI class A
CE class A
C-Tick class A
Safety Approval UL UL
