DFL-900/1500 User Manual Appendix D
System Log Syntax
253
C19 Web filter keyword deleted CONTENT: [C19] Web filter keyword deleted by admin
(192.168.17.100:443). EID=22
C20 Enable web filter keyword
matching
CONTENT: [C20] Enable web filter keyword matching by admin
(192.168.17.100:443). EID=23
C21 Disable web filter keyword
matching
CONTENT: [C21] Disable web filter keyword matching by
admin (192.168.17.100:443). EID=24
C22 Updated POP3 filter exempt
zone configuration
CONTENT: [C22] Updated POP3 filter exempt zone
configuration by admin (192.168.17.100:443). EID=25
C23 POP3 filter exempt zone
added range
CONTENT: [C23] POP3 filter exempt zone added range from
140.126.1.1 to 140.126.1.255 by admin (192.168.17.100:443).
EID=26
C24 Enable POP3 filter CONTENT: [C24] Enable POP3 filter by admin
(192.168.17.100:443). EID=27
C25 Disable POP3 filter CONTENT: [C25] Disable POP3 filter by admin
(192.168.17.100:443). EID=28
C26 POP3 Filter blocking list
updated
CONTENT: [C26] POP3 Filter blocking list updated by admin
(192.168.17.100:443). EID=29
C27 Updated SMTP exempt zone
configuration
CONTENT: [C27] Updated SMTP exempt zone configuration by
admin (192.168.17.100:443). EID=30
C28 SMTP filter exempt zone
added range from
CONTENT: [C28] SMTP filter exempt zone added range from
by admin (192.168.17.100:443). EID=31
C29 Enable SMTP filter CONTENT: [C29] Enable SMTP filter by admin
(192.168.17.100:443). EID=32
C30 Disable SMTP filter CONTENT: [C30] Disable SMTP filter by admin
(192.168.17.100:443). EID=33
C31 SMTP Filter blocking list
updated
CONTENT: [C31] SMTP Filter blocking list updated by admin
(192.168.17.100:443). EID=34
C36 Enable WEB filter CONTENT: [C36] Enable WEB filter by admin
(192.168.17.100:443). EID=39
C37 Disable WEB filter CONTENT: [C37] Disable WEB filter by admin
(192.168.17.100:443). EID=40
F01 Enable/Disable Firewall FIREWALL: [F01] Activated firewall by admin
(192.168.17.102:443).
FIREWALL: [F01] Deactivated firewall by admin
(192.168.17.102:443).
F02 Edit Firewall Rules
F03 Anti-DoS Setup FIREWALL: [F03] Enable Anti-DoS when attack detected by
admin (192.168.17.102:443).
FIREWALL: [F03] Disable Anti-DoS when attack detected by
admin (192.168.17.102:443).
FIREWALL
F04 Reload Firewall Rules FIREWALL: [F04] WAN1 Reload all NAT/Firewall rules for
new WAN IP
L01 Logfile is Full LOG: [L01] logfile is full.
L02 Mail Log LOG: [L02] mail logfile to tom@hotmail.com.
LOG
L03 Remote Syslog Server offline
