DFL-900/1500 User Manual A.3CLI commands list (Rescue Mode)
241
The Full tftp commands are described in the following Table A-3.
Prefix
command
2th
command
3th
command
Postfix command
Example Command description
config FILENAME WORD
ip tftp upgrade config
conf-0101 192.168.1.170
Upgrade configuration file
image from tftp server.
upgrade
FILENAME WORD
(preserve)
ip tftp upgrade image
<FILENAME> 192.168.1.170
preserve
Upgrade system image from
tftp server.
config WORD
ip tftp backup config
192.168.1.170
Backup configuration file
image to tftp server.
ip tftp
backup
image WORD
ip tftp backup image
192.168.1.170
Backup system image to tftp
server.
Table A-3 ip tftp commands description
In the Postfix command, the meanings of keywords are listed here.
WORD: tftp server IP address
FILENAME: Upgrade configuration file image name
(preserve): string “preserve”, this is optional
A.3 CLI commands list (Rescue Mode)
If the original firmware was damaged by some accidents, you may need to recover it with the factory reset process in the rescue
mode. Boot the DFL-1500 and press <tab> or <space> during the 2-second countdown process. You may refer Section
30.5.3 for
details.
Non-privileged mode
Main
commands
Sub
commands
Example Command description
?
? Show the help menu
enable (en)
enable Turn on privileged mode command
exit (ex)
exit Exit command shell
ip
Configure IP related settings
ping
ip ping 202.11.22.33 Send ICMP messages
sys
Configure system parameters
status (st)
sys status Show the mode name and firmware version.
version (ver)
sys version Show the firmware version
Table A-4 Non-privileged mode of rescue mode
Note: If you don’t know what parameter is followed by the commands, just type “?” following the command. Ex “ip ?”. It will show
all the valid suffix parameters from “ip”.
