DFL-900/1500 User Manual Chapter 8
Routing
77
FIELD DESCRIPTION Range / Format EXAMPLE
Activate this rule The policy routing rule is enabled or not. Enabled / Disabled Enabled
Status
Rule name The policy routing rule name. text string GenlManaRoom
Incoming packets
from
Packets comes from which interface
LAN / DMZ
regions
LAN1
Source IP &
Netmask
Verify if the incoming packets belong to the
range of the Source IP/Netmask in the policy
routing rule.
IPv4 format / IPv4
format
192.168.40.192 /
255.255.255.192
Dest IP &
Netmask
Verify if the incoming packets belong to the
range of the Dest IP/Netmask in the policy
routing rule.
IPv4 format / IPv4
format
0.0.0.0 / 0.0.0.0
Service Verify what is the service of this packet?
ANY / TCP / UDP
/ ICMP
Any
Configure src.
port? Type Src.
port
If the service is TCP or UDP, we can choose to
configure or not to configure source port.
Enabled / Disabled No
Type
If we decide to configure source port, we must
choose the port to be single or range.
Single / Range N/A
Src. Port
If we select single at above field, we just have
to fill a port in the first blank space. If we select
range at above field, we need to fill the range of
the ports.
1 ~ 65534 N/A
Configure dest.
port? Type Dest.
port
If the service is TCP or UDP, we can choose to
configure or not to configure destination port.
Enabled / Disabled No
Type
If we decide to configure destination port, we
must choose the port to be single or range.
Single / Range N/A
Condition
Dest. Port
If we select single at above field, we just have
to fill a port in the first blank space. If we select
range at above field, we need to fill the range of
the ports.
1 ~ 65534 N/A
Forward to
If the packet is matched to this rule, which
interface does this packet sent out to?
WAN interfaces WAN1
Action
Nexthop gateway
IP
The next gateway IP address of forwarding
interface.
IPv4 format 210.2.1.6
Table 8-2 Add a policy routing entry
