Appendix B
D-Link 244
Ans：
Please make sure if you follow the setting method as follows.
a. Check your IPSec Setting. Please refer to the settings in the Section 13.4- Step 3.
b. Make sure if you have already added a WAN to LAN policy in the Advanced Settings/Firewall to let the IPSec packets
pass through the DFL-1500. (The default value from WAN to LAN is block.).
When you add a Firewall rule, the Source IP and Netmask are the IP address, PrefixLen/Subnet Mask
in the pages of the Remote Address Type. And the Dest IP and Netmask are the IP Address,
PrefixLen/Subnet Mask in the pages of the Local Address Type.
