DFL-900/1500 User Manual Chapter 5

Remote Management

5.4 Steps

5.4.1 Telnet

Step 1. Setup Telnet

Enter 23 instead of the default 2323 in the

Server Port field. Check the WAN1 checkbox.

Click the

Selected of Secure Client IP

Address

, and then enter the specified IP

address

(140.2.5.1) for accessing

DFL-1500. And click the

Apply.

SYSTEM TOOLS > Remote Mgt. > TELNET

5.4.2 SSH

Step 1. Setup SSH

Enter 22 in the Server Port field. Check the

LAN1/LAN2 checkbox. Click the ALL of Secure

Client IP Address for accessing DFL-1500.

And click the Apply.

SYSTEM TOOLS > Remote Mgt. > SSH

5.4.3 WWW

Step 1. Setup WWW

Check the LAN1 checkbox, and enter the new

Server Port 8080 that will be accessed by the

user’s browser (http://192.168.40.254:8080). In

the Secure Client IP Address field, we select the

specified IP address “192.168.40.2”. And click the

Apply button.

Note that the Secure Client IP Address is the

IP address which can be used to configure

DFL-1500.

SYSTEM TOOLS > Remote Mgt. > WWW

9 Warning message

If you click the Selected of Secure Client IP Address and then enter the specified IP address which is not the same as current

login IP address, a warning message will appear to notice you that “Warning! If you are connecting to this Firewall with WWW, this

action may disconnect your session. Please remember the settings and reconnect to the firewall again.” after applying the settings.
