Part V
Virtual Private Network
D-Link 164
Step 5. Add Firewall rule settings
Additionally, because the traffic of WAN to
LAN default is blocked. So we must add a
firewall rule to allow the local area of remote
side to pass through the DFL firewall. Please
refer the section
13.4.1 for the full description
and examples.
N/A
20.4.2 Create a custom MMC console
Step 1. Run mmc
From Windows desktop, go to Start > Run, and
in the Open textbox type mmc, click OK.
Step 2. Add Snap-in
On the Console window, click Add/Remove
Snap-In.
Step 3. Add a Standalone Snap-in
In the Add/Remove Snap-In dialog box, click
Add.
