Appendix D
D-Link 252
A03 Change Password AUTH: [A03] admin change system password
(192.168.17.102:443).
BANDWIDTH: [B01] Enable bandwidth management by admin
(192.168.17.100:443).
BANDWIDTH
B01 Enable/Disable Bandwidth
Management
BANDWIDTH: [B01] Disable bandwidth management by admin
(192.168.17.100:443).
C01 Web filter categories
configuration updated
CONTENT: [C01] Web filter categories configuration update by
admin (192.168.17.100:443). EID=6
C02 Web filter added trusted host CONTENT: [C02] Web filter add trusted host by admin
(192.168.17.100:443). EID=6
C03 Web filter deleted trust host CONTENT: [C03] Web filter deleted trust host by admin
(192.168.17.100:443). EID=6
C04 Web filter added forbidden
domain
CONTENT: [C04] Web filter added forbidden domain by admin
(192.168.17.100:443). EID=7
C05 Web filter deleted forbidden
domain
CONTENT: [C05] Web filter deleted forbidden domain by admin
(192.168.17.100:443). EID=8
C06 Enable web-filter access
control
CONTENT: [C06] Enable web-filter access control by admin
(192.168.17.100:443). EID=9
C07 Disable web-filter access
control
CONTENT: [C07] Disable web-filter access control by admin
(192.168.17.100:443). EID=10
C08 Web filter URL keyword
added
CONTENT: [C08] Web filter URL keyword added by adimin
(192.168.17.100:443). EID=11
C09 Web filter URL keyword
deleted
CONTENT: [C09] Web filter URL keyword deleted by admin
(192.168.17.100:443). EID=12
C10 Enable web filter url matching CONTENT: [C10] Enable web filter url matching by admin
(192.168.17.100:443). EID=13
C11 Disable web filter url
matching
CONTENT: [C11] Disable web filter url matching by admin
(192.168.17.100:443). EID=14
C12 Updated web filter exempt
zone configuration
CONTENT: [C12] Updated web filter exempt zone configuration
by admin (192.168.17.100:443). EID=15
C13 Web filter exempt zone added
range
CONTENT: [C13] web filter exempt zone added range from
140.126.1.1 to 140.126.100.255 by admin (192.168.17.100:443).
EID=16
C14 Updated ftp filter exempt
zone configuration
CONTENT: [C14] Updated ftp filter exempt zone configuration
by admin (192.168.17.100:443). EID=17
C15 FTP filter exempt zone added
range
CONTENT: [C15] FTP filter exempt zone added range from
140.126.1.1 to 140.126.255.255 by admin (192.168.17.100:443).
EID=18
C16 Updated ftp filter blocked file
configuration
CONTENT: [C16] Updated ftp filter blocked file configuration
by admin (192.168.17.100:443). EID=19
C17 FTP Filter blocking list
updated
CONTENT: [C17] FTP Filter blocking list updated by admin
(192.168.17.100:443). EID=20
CONTENT
C18 Web filter keyword added CONTENT: [C18] Web filter keyword added by admin
(192.168.17.100:443). EID=21
