Part III
NAT & Routing
D-Link 64
FIELD DESCRIPTION Range / Format EXAMPLE
Network Address
Translation Mode
Determine what NAT type you are using in your network
topology.
Refer more information in the section
7.5.5.
None /
Basic /
Full Feature
Basic
BUTTON DESCRIPTION
Reset NAT Rules Reset NAT rules to the default status
Reset Server Rules Clear all the Virtual Server rules.
Apply Apply the settings which have been configured.
Table 7-1 Determine Network Address Translation Mode
Step 2. Check NAT Rules
As described in the previous sections, the
DFL-1500 has set the rules for the LAN/DMZ
zones. They all belong to the Many-to-One
(M-1) type that will map many private addresses
to the automatically chosen public IP address.
When the WAN interfaces change the IP, these
rules do not require any manual modifications for
the changed public IP addresses. The rules will
reload the new settings automatically. Besides,
you cannot insert/edit any rules under the Basic
mode.
ADVANCED SETTINGS > NAT > NAT Rules
Step 3. Switch the NAT Mode
Select the Full Feature from the list of
Network Address Translation Mode. Click
Apply. After applying the setting, the page will
highlight a warning saying that the rules are no
more automatically maintained by the DFL-1500.
If you change the LAN/DMZ IP settings, you have
to manually update related rules by yourself.
Otherwise, hosts in your LAN/DMZ cannot
establish connections to the hosts in the WAN
side.
ADVANCED SETTINGS > NAT > Status
