A.3
D-Link 242
Privileged mode
Main
commands
Sub commands
Example Command description
?
? Show the help menu
disable (dis)
disable Turn off privileged mode command
exit (ex)
exit Exit command shell
ip
Configure IP related settings
arp
ip arp status Show the ip/MAC mapping table
dns
ip dns query www.yam.com.tw Show the IP address of the www.yam.com.tw.
ifconfig
ip ifconfig INTF1 192.168.1.100
255.255.255.0
Configure the ip address of each port
ping
ip ping 202.11.22.33 Send ICMP echo request messages
tftp
ip tftp upgrade image
<FILENAME> 192.168.1.170.
Upgrade firmware from tftp server.
sys
Configure system parameters
halt
sys halt now Shutdown system
reboot
sys reboot now Reboot system
resetconf
sys resetconf now Reset system configuration to default settings
status (st)
sys status Show the mode name and firmware version.
version (ver)
sys version Show the firmware version
Table A-5 Privileged mode CLI commands
