DFL-900/1500 User Manual Chapter 13
Virtual Private Network – IPSec
111
ESP Algorithm
ESP Algorithm may be grouped by the items
of the Encryption and Authentication
Algorithms or execute separately.
We can select below items, the Encryption and
Authentication Algorithm combination or the
below item Authentication Algorithm singly.
Here Encryption Algorithms include
DES(64 bits), 3DES(192 bits) and
AES(128/192/256 bits)
Authentication Algorithms include
MD5(128 bits) and SHA1(160 bits)
Encrypt and
Authenticate
(DES, MD5) /
Encrypt and
Authenticate
(DES, SHA1) /
Encrypt and
Authenticate
(3DES, MD5) /
Encrypt and
Authenticate
(3DES, SHA1) /
Encrypt and
Authenticate
(AES, MD5) /
Encrypt and
Authenticate
(AES, SHA1) /
Encrypt only
(DES) /
Encrypt only
(3DES) /
Encrypt only
(AES) /
Authenticate only
(MD5) /
Authenticate only
(SHA1)
Encrypt and
Authenticate
(DES, MD5)
AH Algorithm Select Authentication Algorithm
Authenticate
(MD5) /
Authenticate
(SHA1)
Disabled
Pre-Shared Key The key which is pre-shared with remote side. text string 1234567890
Table 13-4 Related field explanation of adding an IPSec policy rule
