D-Link DFL-1500 [138/271] Chapter 14

Part V

Virtual Private Network

D-Link 130

Step 5. Add a Firewall rule

Same as at DFL-1. We need to add an extra

firewall rule to allow IPSec packets to come from

internet. So here we select WAN1-to-LAN1

direction, and click Insert button.

ADVANCED SETTINGS > Firewall > Edit Rules

Step 6. Customize the Firewall rule

Enter the Rule Name as AllowVPN, Source IP

as WAN1_VPNB (192.168.40.0), and Dest.

IP as LAN1_VPNB (192.168.88.0). Click

Apply to store this rule.

ADVANCED SETTINGS > Firewall > Edit Rules > Insert

Step 7. View the result

Now we have inserted a new rule before the

default firewall rule. Any packets from

192.168.40.0/24 to 192.168.88.0/24 will

be allowed to pass through the DFL-1500 and

successfully access the 192.168.88.0/24

through the VPN tunnel.

ADVANCED SETTINGS > Firewall > Edit Rules
