DFL-900/1500 User Manual Appendix D
System Log Syntax
255
S06 Startup/Shutdown HTTPS
Server
SYSTEM: [S06] HTTPS started.
S07 Startup TELNET Server
S08 Set Interface IP Address SYSTEM: [S08] WAN1: IP Address:
192.168.17.102/255.255.255.0. (192.168.17.102:443).
S09 IP Alias SYSTEM: [S09] LAN1: Add IP address alias
192.168.1.2/255.255.255.0 by admin (192.168.17.102:443).
SYSTEM: [S09] LAN1: Delete IP address alias
192.168.1.2/255.255.255.0 by admin (192.168.17.102:443).
SYSTEM: [S09] LAN1: Change IP address alias
192.168.1.2/255.255.255.0 to 192.168.1.3/255.255.255.0 by
admin (192.168.17.102:443).
S10 Set Host Name SYSTEM: [S10] HostName:DFL-1500, set by admin
(192.168.17.102:443).
S11 Set Domain Name SYSTEM: [S11] Domain Name: dlink.com, set by admin
(192.168.17.102:443).
S12 Enable/Disable DDNS SYSTEM: [S12] Enable Dynamic DNS with hostname
wall.adsldns.org on WAN1 by admin (192.168.17.102:443).
SYSTEM: [S12] Disable Dynamic DNS on WAN1 by admin
(192.168.17.102:443).
S13 Enable/Disable DNS Proxy SYSTEM: [S13] Enable DNS proxy by admin
(192.168.17.102:443).
SYSTEM: [S13] Disable DNS proxy by admin
(192.168.17.102:443).
S14 Enable/Disable DHCP Relay SYSTEM: [S14] Enable DHCP relay by admin
(192.168.17.102:443).
SYSTEM: [S14] Disable DHCP relay by admin
(192.168.17.102:443).
S15 Set Date/Time SYSTEM: [S15] System time update with NTP server
tock.usno.navy.mil, set by admin (192.168.17.102:443).
SYSTEM: [S15] System time update to 2003-10-10 13:33:25, set
by admin (192.168.17.102:443).
S16 Set System Auto Timeout
Lifetime
SYSTEM: [S16] System auto timeout changed to 45 minutes by
admin (192.168.17.102:443).
S17 Interface PORTS
Configuration
(WAN/LAN/DMZ)
S18 Backup Configuration SYSTEM: [S18] Backup configuration file by admin
(192.168.17.102:443).
S19 Restore Configuration SYSTEM: [S19] Restore configuration file by admin
(192.168.17.102:443).
S20 Factory Reset SYSTEM: [S20] Factory Reset to default settings by admin
(192.168.17.102:443)
S21 Firmware Upgrade SYSTEM: [S21] Firmware upgraded by admin
(192.168.17.102:443)
S22 Setup TELNET Server
