D-Link DFL-1500 [48/271] Chapter 3
![D-Link DFL-1500 [48/271] Chapter 3](/views2/1018635/page48/bg30.png)
Part II
Basic Configuration
D-Link 40
Step 3. See the IP alias setting in the
“WAN1 IP” page
After entering the IP alias address, it will
show the result in the “WAN1 IP” page.
Warning: If you select Fixed IP Address as
your WAN link type and set any IP alias, the
previous set IP aliases will disappear when you
try to exchange the WAN link type to other type
such as DHCP or PPPoE.
BASIC SETUP > WAN Settings > WAN1 IP > Fixed IP Address
