Part VIII
Load BalancerBandwidth ManagementHigh Availability
D-Link 208
25.4 Steps
25.4.1 Outbound Load Balancer
Step 1. Make Firewall rules the same
Since the traffic will be intelligently load-balanced
among the WAN links, the Firewall settings for all
WAN links should be set to the same settings. For
example, you have to make sure that all
LAN1-to-WAN1 Firewall rules are the same as
those in LAN1-to-WAN2, LAN2-to-WAN1, and
LAN2-to-WAN2 rules. Otherwise, the traffic may
be blocked by the firewall rules accidentally due
to the load balancing decision.
ADVANCED SETTINGS > Firewall > Edit Rules
Step 2. Enable outbound WAN load
balancer
Check the Enable Outbound WAN Load
Balancer checkbox, click the Apply.
ADVANCED SETTINGS > Load Balancer > Outbound
Note that the priority among the policy route, static route, and WAN load balancer are explicitly shown as Policy Route >
Static/Default Route > WAN Load Balancer. If there are conflicted settings among these three settings, the route will be chosen
according to the priority.
