Part V
Virtual Private Network
D-Link 110
Remote Address
Type
Determine the method to connect to the local
side of VPN by using the remote subnet or the
remote single host.
Subnet Address /
Single Address
Subnet Address
IP Address The remote IP address IPv4 format 192.168.88.0
Prefix
Len/Subnet Mask
The remote IP Netmask
IPv4 format 255.255.255.0
Negotiation
Mode
Choose Main or Aggressive mode, see Chapter
12 for details.
Main / Aggressive Main
Encapsulation
Mode
Choose Tunnel or Transport mode, see Chapter
12 for details.
Tunnel / Transport Tunnel
Outgoing
Interface
The WAN interface you are going to build
IPSec tunnel with.
WAN interfaces WAN1
Peer’s IP Address
The IP address of remote VPN device. The IP
address may be fixed (Static) or dynamic.
Static IP /
Dynamic IP
Static IP 210.2.1.1
My Identifier
Fill your information in this field. The filled
information will be provided for the IPSec
tunnel establishment.
IP Address /
FQDN (domain
name) /
User FQDN (mail
box)
IP Address
Action
Peer’s Identifier
Fill the information of peer VPN device in this
field. The filled information will be provided
for the IPSec tunnel establishment.
IP Address /
FQDN (domain
name) /
User FQDN (mail
box)
IP Address
